| using 2pieces of safety tempered glass | Internal blinds 22X64 |
|---|
BLINDS Glass
Various sizes for your choice
Various shape fit for kinds of different doors
A. Decorative glass panel for door.
B. Caming available: brass, nickel, patina.
C. Electroplating caming available: chrome, black chrome, satin
nickel
D. Competitive price with good quality.
F. Using tempered glass on both side of the glass unit, which meet
ANSI, BSI standards.
G. Using decorative glass not only personalize your home, but also
add to your home's curb appeal.
H. Custom design availble.
Advantages:
A. Modern style, unique
B. Heat resistance, notice resistance, keeping warm
C. Oxygenation resistance, bump resisitance
D. Bear high & low temperature
Energy Efficiency
Our warm edge spacer system creates energy-efficient, water- and
air-resistant doorlites. And our blinds are available with
energy-saving Low-E glass.
| shading coefficient | Slates Vertical State | Slates Parallet State | Slates Close State |
| Mini-blind Glass | 0.18 | 0.83 | 0.9 |
| Heat Transmission | Slates Vertical State | Slates Parallet State | Slates Close State |
| Mini-blind Glass | K=2.0W/(m2.k) | K=2.7W/(m2.k) | K=2.9W/(m2.k) |
| Broken Bridge Aluminum | K=1.7W/(m2.k) | K=2.5W/(m2.k) | K=2.6W/(m2.k) |
| Low-E Mini-blind Glass | K=1.8W/(m2.k) | K=2.1W/(m2.k) | K=2.4W/(m2.k) |
SPECIFICATION:
Size :maximum 2440mm*3660mm
minimum 300mm*300mm
Aluminum Frame thickness:6mm , 9mm , 12mm ,15mm.
Glass thickness: 4mm,5mm,6mm,8mm,10mm,12mm.
Colour of glass:as your requests
You can choose various combinations
| Product Name | Insulated Glass |
| Brand | SYSEN |
| Place of Origin | Foshan, Guangdong, China |
| Thickness | From 4mm+6A+4mm to 15mm+15A+15mm |
| Size | Minimum Size | 250mm×350mm |
| Maximum Size | 2540mm×4500mm |
| Color | Clear, Blue, Green, Dark brown, etc. |
| Type of Sheet Glass | Float glass, Tinted glass, Coated glass, etc. |
| Aluminum Strip Width | 6 mm,9 mm,12 mm,15mm, etc. |
| Insulating Gas | Argon |
| Packing Details | (1)Interlay paper or plastic between two sheets;
(2)Seaworthy wooden crates;
(3) Iron belt for consolidation. |
| Quality Standard | ICGG,IGMA,CCC |
| Application | (1)Facades and curtain walls
(2)Skylights
(3)Green house |
| Types | Low-e insulated glass,Insulated tempered glass,Insulated tempered
glass,Insulated laminated glass,Coated insulated glass,Colored
insulated glass,Curved insulated glass. |
| Note: ZRG glass can be customized according to the given
specifications and colors from clients. |
Light Cont
Angle adjustment is possible to freely and control the light and
line-of-sight.
The insulation resistance of the multi-layer glass, it was plus the
heat shield by the blind which is sandwiched between the glass and
the glass. By the blind angle adjustment, it will be able to
further up the insulation effect while controlling the light and
the line of sight.
